Lithium Battery Charger Protection Module (BMS) 3S 100A 12V

This protection board is in common use lithium battery protection board (you can adjust for how many strings to be used) Specified chip, stable performance, support disconnection protection, over-current protection, over-discharge protection, overcharge protection, with balance, etc. A common use for “same port” and “different port”, the protection board uses 15 high-power of ultra-low resistance MOS tubes (discharge of 8, charging of 7), in the same port mode can support the discharge current 60A, charging current 60A; different port mode discharges current 80A, charging current 60A. Can used for (3.7V) battery packs etc. Specifications: Single-cell battery overcharge protect voltage: 4.21-4.29 V Single-cell battery overcharge protects recover voltage: 4.14-4.24 V Overcharge protect delay : 1.5-2.5S Single cell battery over-discharge protect voltage : 2.72-2.88 V Single cell battery over-discharge protect recover voltage : 2.9-3.1 V Over charge protective current:100A Over discharge protective current:100A Over-discharge protect delay : 0.5-1.5S Temperature protects: Yes, have a Temperature control interface. Disconnect protect: Yes Shortage protection: Yes Shortage delay: 100-600 uS Shortage protects recover mode: Offload release. balance function: yes Ampere balance (Current): 60MA Current balance accuracy: 4.14-4.24V Material: PCB Size:60x42x4mm
